| ENGINE | ||
| Engine Type | Single-cylinder, 4-stroke, Liquid-cooled, SOHC | |
| Displacement | 149 cc | |
| Bore x Stroke | 57.3 mm x 57.9 mm | |
| Compression Ratio | 10.6 : 1 | |
| Maximum Power | 13.4 hp @ 8,500 rpm | |
| Maximum Torque | 10 ft·lb @ 6,000 rpm | |
| Fuel Supply | EFI | |
| Ignition | TLI | |
| Starter | Kick / Electric | |
| Transmission | Belt Drive w/ Automatic CVT | |
| CHASSIS | ||
| Front Suspension | Telescopic | |
| Front Travel | N / A | |
| Rear Suspension | Coil Spring Oil Damped | |
| Rear Travel | N / A | |
| Front Brake | Disc Ø 220 mm | |
| Rear Brake | Disc Ø 190 mm | |
| Front Tire | 100 / 90 - 12 | |
| Rear Tire | 110 / 90 - 12 | |
| DIMENSIONS | ||
| Overall Length | 74.8 inches | |
| Overall Width | 27.9 inches | |
| Overall Height | 43.3 inches | |
| Seat Height | 29.9 inches | |
| Wheelbase | 51.2 inches | |
| Ground Clearance | 4.7 inches | |
| Fuel Tank | 1.6 gallons | |
| Weight | 260 pounds | |
| OTHER | ||
| Colors | Black, Yellow | |
| Warranty | 12-month / 12,000-mile Limited Warranty Coverage (learn more) | |
|
||
|
